3.5 Tons Lithium Electric Forklift CPD35 3500KG

Ask Lasest Price
Brand Name :	yangft
Price :	negotiable
Delivery Time :	10 DAYS
Payment Terms :	Western Union, MoneyGram, T/T

Add to Cart

Product Details
Company Profile

3.5 Tons Lithium Electric Forklift CPD35 3500KG

Built with simplistic design in mind, Yangft electric forklifts are quiet, compact with small turning radius, and offers great handling. With customized algorithms, the 7L electric forklifts offers impressive performance, especially on slopes. The forklifts are easy to maintain and have proven dependable and reliable.

Qingdao YangFT Electric Forklift Truck Parameter List
Model				CPD35
CHARACTERISTICS	POWER			ELECTRIC
	CAPACITY		kg	3500
	LOAD CENTRE		mm	500
	LIFT HEIGHT		mm	3000
	MIN. TURNING RADIUS		mm	2320
PERFORMANCE	TRAVEL SPEED	LOAD/NO LOAD	km/h	13/14
PERFORMANCE	LIFT SPEED	LOAD/NO LOAD	mm/s	280/360
DIMENSIONS	TOTAL LENTH	WITHOUT FORK	mm	2520
	TOTAL WIDTH		mm	1225
	MAX. HEIGHT		mm	4210
	MAST HEIGHT		mm	2065
CHASSIS	TYRE	FRONT		23x9-10
	TYRE	REAR		18x7-8-14PR
	WHEELBASE		mm	1700
	SERVICE WEIGHT	NO LOAD	Kg	5400
POWER	BATTERY	electric tension	V	80
	BATTERY	capacity	Ah	500
	MOTOR	Drive motors	KW	14
	MOTOR	Hydraulic motor	KW	13

Safety

Unibody frame

Boltless, unibody design increases strength by up to 20%, improves safety, and allows the forklift to handle uneven surfaces and curvy paths, and can withstand long, rigorous transporting operations.

Mast made with German steel* offers unparalleled rigidity and durability.

Anti-slip function automatically activates on slopes ensures safety.

Electronic Lock Valve (Optional)

Adds more security by locking the lifting and tilting system when the operator is away from the seat.

Comfort

Comfortable Operating Space

Ergonomic design minimizes operator fatigue from long working hours, increases operating space and improves work efficiency.

Adjustable Steering Wheel

Provide convenience and can customize to the operator's desired position.

Intelligent multi-function display

Multifunction display shows driving speed, battery charge, total hours, operator information and all warnings in one compact, easy to read instrument.

Qingdao YangFT Electric Forklift C Series Parameter List(2 Ton to 4.5 Ton)
Model					CPD35
CHARACTERISTICS	POWER				LITHIUM BATTERY
	CAPACITY		kg		3500
	LOAD CENTER		mm		500
	LIFT HEIGHT		mm	h	3000
	MAST TILT ANGLE	F/R	Deg		6/12
	MIN. TURNING RADIUS		mm	Wa	2410
	MIN. GROUND CLEARANCE	MAST	mm		135
	MIN. GROUND CLEARANCE	FRAME	mm		140
	OVERHEAD GUARD HEIGHT		mm	h3	2150
	FRONT LOAD DISTANCE		mm		490
PERFORMANCE	MAX.TRAVELING SPEED	LOAD/NO LOAD	km/h		12/13
	MAX.LIFTING SPEED	LOAD/NO LOAD	mm/s		400/420
	MAX. GRADEABILITY	LOAD/NO LOAD	%		13/14
DIMENSIONS	TOTAL LENTH	WITH FORK	mm	L1+L2	3770
	TOTAL LENTH	WITHOUT FORK	mm	L2	2700
	TOTAL WIDTH		mm	b	1225
	MAX. HEIGHT	BACKREST	mm	h4	4265
	MAST HEIGHT		mm	h1	2115
CHASSIS	TYRE	FRONT			28*9-15-12PR
	TYRE	REAR			6.50-10-10PR
	WHEELBASE		mm	L2	1700
	WHEELTREAD	F/R	mm		1000/970
	SERVICE WEIGHT	NO LOAD	Kg		4550
POWER	BATTERY	VOLTAGE	V		76.8
	BATTERY	CAPACITY	Ah		230
	MOTOR	DRIVE MOTORS	KW		10
	MOTOR	OIL PUMP MOTOR	KW		12
